I. Daily maintenance

1, first around the mechanical rotation two circles to check the appearance and mechanical chassis is strange, and whether the rotary support has oil outflow, and then check the deceleration brake device and track bolt fasteners, the tightening, the replacement in time, if it is a wheel excavator will need to check whether the tire is abnormal, and the stability of air pressure.

2, Check whether the wear of the excavator will greatly increase the resistance in the construction process, seriously affect the work efficiency and increase the wear of equipment parts.

3, Check the barrel and cylinder for cracks or oil leaks. Check the battery electrolyte to avoid being below the low-level line.

The 4, air filter element is an important part to prevent a large amount of dust-containing air from entering the excavator. It should be regularly checked and cleaned, and replaced in case of failure.

5, Check to add oil, oil, hydraulic oil, coolant, etc., and select oil as required in the instructions and remain clean.

6, Check the front window cleaning fluid level, check and adjust the air conditioning, and clean the cab floor.

7, When cleaning the cooling system inside, after the engine is fully cooled, slowly release the water inlet cover and release the pressure inside the water tank before releasing the water. Do not clean while the engine works, the high speed rotating fan causes danger, and park the machine on the level ground when cleaning or replacing the coolant.

II. Regular maintenance

Change the fuel element and additional fuel element after the 1, new works 250H and check the clearance of the engine valve.

2, per 100H

Arm cylinder head pin shaft, arm pin, arm cylinder rod end, arm cylinder rod pin, bucket rod, rod connecting pin, bucket cylinder head pin, half rod connecting pin, bucket rod, bucket cylinder rod end, bucket cylinder head pin, rod connection pin, check the oil level (plus oil) in the rotary mechanism box, and discharge water and sediment from the fuel tank.

3, per 250H

Check the oil level (add gear oil) in the final gearbox, check the battery electrolyte, replace the oil in the oil pan of the engine oil, replace the engine filter element, lubricate the rotary support (2), check the tensibility of the fan belt, check the tensibility of the air conditioning compressor belt, and adjust.

4, per 500H maintenance items

Conduct each 100 and 250H maintenance items, replace the fuel element, check the height of the rotary pinion grease (add grease), check and clean the radiator, the radiator oil cooler radiator and cooler radiator, replace the hydraulic oil element, replace the oil in the final transmission box (only first at 500H, after 1000H once), clean the air element inside and outside the air conditioner system, and replace the hydraulic oil vent element.

5, maintenance items per 1,000 H

At the same time, maintain every 100,250,500 and 500H, replace the oil in the rotary mechanism box, check the oil level (return oil) of the damper housing, check all fasteners of the turbocharger, check the turbocharger rotor, check and replace the tensioning of the generator belt, replace the corrosion proof filter element, and replace the oil in the final transmission box.

6, maintenance items per 2,000 H

Complete the maintenance items per 100,250,500,500 and 1000H, clean the hydraulic tank filter screen, clean, check the turbocharger, check the generator, starting motor, check the engine valve clearance (and adjust), and check the vibration damper.

7. Maintenance above 4000H

Increase inspection of water pumps per 4000H and replace hydraulic oil per 5000H.

8, for long storage

During the long-term storage of the excavator, To prevent the rust of the hydraulic cylinder piston rod, Work devices shall be placed ground, Complete machine is washed and dry and stored in an indoor dry environment, For outdoor storage, The machine shall be parked on a well-drained cement ground, Fill it with the fuel tank before storage, Lubricate each parts, Replace the hydraulic oil and the engine oil, Apply a thin layer of butter to the exposed metal surface of the hydraulic cylinder piston rod, Remove the negative terminal of the battery, Or remove the battery and store it separately, Add an appropriate proportion of antifreeze to the cooling water according to the minimum ambient temperature, Start the engine and operate the machine once in the month, To lubricate the moving components, Charge the storage battery simultaneously, Turn on the air conditioning and cooling operation for 5-10min.

How to remove the dirt from the fuel tank of the excavator

1, blowing method

That is, retain part of the diesel fuel in the tank, and then pass the 19.6~29.4KPa compressed air into a plastic pipe at the bottom of the tank, make the diesel roll and clean, and constantly change the position and direction of the bottom end of the gas pipe to clean the whole tank. Release the diesel oil of the fuel tank immediately after blowing, and the excavator to repair the impurities suspended in the oil out with the diesel oil. If the diesel oil is dirty, clean again with the upper method until the oil is free of impurities.

2, steam method

Put the diesel fuel, remove the fuel tank, then fill the diesel tank, guide the steam from the fuel outlet from the fuel outlet, make the water in the diesel tank boil about 1H. In this way, the glue attached to the inner wall of the tank and the residual diesel molecules can be dissolved in the water. Light-quality dirt was surfaced and washed away. For two consecutive times, the diesel tank can be flushed clean.

3, solvent method

Clean the excavator diesel tank with hot water, blow it dry with compressed air to remove its internal diesel vapor, and finally soak the diesel tank in an aqueous solution containing 10% sodium hydroxide. Wash se the inside and outside of the diesel tank with clean water. If external rust is found, brush it clean with a steel wire brush.
