300 kg Wheel Skid Steer Loader
  • 300 kg Wheel Skid Steer Loader
Product manual available for download at any time
Please leave your information below for more product information
Skid Steer Loader
300 kg Wheel Skid Steer Loader
Engine Model
Perkins
Operation Weight
1500 kg
Bucket Capacity
0.2 m³
Manual Download
Service and support Dealer inquiry Accessories
Get a quote
300 kg Wheel Skid Steer Loader
  • Characteristics
  • parameters
  • cases
  • recommendations
Characteristics

1.Dual Accelerator Control Model: manual operated + foot operated, easy to operate

2.Cabin design in safe and comfortable: big view, all of instruments set up in forward.Front light, rear light, turning light, horn, back up buzzing

3.Centre monitor: fuel oil level and temperature gauge, water temperature gauge, oil pressure, chronometer, indicator light, warning lamp and so on.

4.Optimization design, high strength chassis. Three kinds of driving modes
（1）Chain drive (supply power to four wheels through two-side motors and chain)

（2）Gear drive (supply power to four wheels through two-side motors and gear)

（3）Direct drive (drive the four wheels by four motors)

5.Hydraulic quick-change coupler is the same as BOBCAT, and is suitable to our skid steer loader attachments as well as foreign attachments

6.Equip with oversize radiator and oil tank, for satisfying the continues working requests in tropical zone


parameters
ModelTDS30
 Operating load (kg)300
 Max Speed（km/h）9
Rated flux (L/min)37
High Flow Flux (L/min)
Tire（track） model23×8.5-15
Rated power (Kw)18.4
Fuel tank capacity (L)25
self weight bucket (kg)1500
Bucket capacity (m³)0.2
Overall operating height (mm)3126
Height to bucket hinge pin (mm)2399
Hheight to top of cab (mm)1813
Height to bottom of level bucket(mm)2399
Without bucket length（mm）1918
Overall length with bucket(mm)2560
Dumping angle at maximum height(° )36
Dumping height(mm)1882
Dumping reach(mm)458
Rollback o bucket on ground(° )24
Rollback of bucket at full height(° )97
Wheelbase(mm)722
Ground clearance(mm)148
Angle of departure(° )28
Front turning radius without bucket(mm)971
Front tuning radius(mm)1557
Rear tuning radius(mm)1146
Rear axle to bumper (mm)738
Tread width (mm)747
Width (mm)900
Bucket width (mm)914
